36V DC Fire Exit Door Release Button 3A ABS with Dull Polish Finish
Dettagli:
| Luogo di origine: | Cina |
| Marca: | JUNSON |
| Certificazione: | CE |
| Numero di modello: | JS-GR01 |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 50pcs |
|---|---|
| Prezzo: | Negoziabile |
| Imballaggi particolari: | pieno di cartone |
| Tempi di consegna: | 2-7 giorni lavorativi dopo aver ricevuto il pagamento |
| Termini di pagamento: | T/T, PayPal o Western Union in anticipo |
| Capacità di alimentazione: | 20,000pcs al mese |
|
Informazioni dettagliate |
|||
| Marca: | Junson | Modello: | JS-GR01 |
|---|---|---|---|
| Materiali: | Alloggio dell'ABS | contatto: | CO/NC/COM |
| Misurare: | 86*86*50mm | Disponibile: | Sistema di sicurezza |
| Nome prodotto: | Rilascio della porta | Voltaggio: | Max 36V DC |
Descrizione di prodotto
JS-GR01 fire exit door release button operates on 36V DC, 3A load. Made of durable ABS with dull polish finish, it ensures reliable performance and quick emergency access for secure exit solutions.
Parameter List
| Size | 86 * 86 * 50mm |
| Materials | ABS housing |
|
Thickness of materials
|
3mm |
| Voltage: Max | 36 V DC |
| Maximum current | 3A |
| Dry contact | No,NC,COM |
| Finishing |
Sandblast finishing
|
| Optional accessories | Transparency cover |
| Facing finishing | Fireproofing materials, dull polish |
| Color | Green, Yellow, Red, White |
|
Mechanical life
|
500000 times
|
| Operation temperature | -10-55℃ |
| Operation Humidity | 0-95℃ |
| Available |
All kind of Emergency exit
|
Features
-
Emergency Release: Designed for quick and safe door unlocking in emergencies.
-
Fire-Retardant Material: Built with high-quality, flame-resistant materials for added safety.
-
Color Options: Available in red, green, white, and yellow.
-
Output Configuration: Single output with NO/NC/COM terminals.
-
Electrical Rating: Supports up to 3A @ 36VDC max.
-
Wide Application: Suitable for escape doors, emergency exits, and safety access points.
